Pleiad G4 Flex
22890 Pleiad G4 22890
A small downlight with very excellent technical lighting properties. Two different luminous fluxes with high colour reproduction. Rotatable 355º and tilts 45º.
Installation
Recessed mounting in unventilated or ventilated suspended ceilings. Separate ballast and installation clip for easy and tool-free installation supplied as standard. An assembly plate must be used when mounting on soft tile ceilings, see accessories. For detailed information, see the installation instructions.
Connection
Connection in separate driver box. Snap-in terminal block 3x1.5 mm², 5x1.5 mm² when dimming. The luminaire body and driver are interconnected with a snap-in connector.
Design
Luminaire body in cast , white aluminium (RAL 9003). Visible reflector ring in white aluminium (RAL 9003).
Reflector
Reflector of black enamelled aluminium (RAL 9005). Reflector ring in white aluminium (RAL 9003). Lens of clear acrylic.
Miscellaneous
IP 20 above a suspended ceiling. Luminaire body Class III. The supplied driver must be connected to the protective earth. For loads in the suspended ceiling system, follow the selected suspended ceiling supplier’s recommendation. Also available with Dim 2 Warm.
Media
Pleiad G4 – Installation
Pleiad G4
Pleiad is a classic that never stagnates. Through continuous development, the luminaire has been improved decade after decade. Pleiad G4 today performs up to 170 lm/W, which meets new lighting needs and achieves high...
More about the family Pleiad G4Other products
Document
Customise with Fagerhult Configure
Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.
- Adapt and optimise the luminaire
- Download unique data sheet and light data files
- To order, contact your sales representative
Specification
The articles listed below are examples.
Use Fagerhult Configure to adapt and optimise your own version of Pleiad G4 Flex by selecting CRI, colour temperatures, optics, luminous flux, accessories, etc.
Filter
Showing 4 of 0 articles
| Art.no. | System Wattage | Lumen output | CCT, K | CRI | Diamater, mm | Reflector | Light distribution | Light control | CLO function active | |
|---|---|---|---|---|---|---|---|---|---|---|
| Art.no. | System Wattage | Lumen output | CCT, K | CRI | Diamater, mm | Reflector | Light distribution | Light control | CLO function active | |
| 73200-402 | 12 | 1136 | 3000 | 80 | 122 | Black | Narrow Beam, 25 | DALI/Phase-pulse | Yes | |
| 73201-402 | 12 | 1185 | 4000 | 80 | 122 | Black | Narrow Beam, 25 | DALI/Phase-pulse | Yes | |
| 73204-402 | 12 | 1290 | 3000 | 80 | 122 | Black | Medium Beam, 38 | DALI/Phase-pulse | Yes | |
| 73205-402 | 12 | 1345 | 4000 | 80 | 122 | Black | Medium Beam, 38 | DALI/Phase-pulse | Yes |
