Pondero

21809 Pondero 21809

See items

A pendant workplace luminaire that produces direct/indirect light. The Beta Opti louvre ensures high efficiency and optimal light comfort.

Installation

Wire pendant. Luminaire bracket with friction lock included in the luminaire.

Connection

For connection with 230 V built-in LED driver. Supplied with 1.5 m transparent cable.

Design

Luminaire body of untreated steel sheet and end caps in untreated aluminum. Transparent tube in acrylic.

Louvre

Beta Opti – double parabolic reflector louvre with satin matt metallised aluminium side and cross-blades with an integrated opal film that minimises the risk of uncomfortable glare from the diodes

Light distribution

Direct/indirect 93/7.

Dimming

DALI/phase-pulse control as standard. Luminaire with DALI/phase pulse control and CLO (Constant Light Output) as standard.
–Organic Response – PIR sensor with presence and daylight control. All luminaires act as master/slave with IR communication.

Accessories

Fittings and additional components sold separately.

Miscellaneous

CRI 90 alt CLO L100 100 000h available upon request. CLO (Constant Light Output) means that the luminaire provides the same amount of light for the duration of its specified burn-time.

Media

Organic Response – How it works

Pondero

A flirt with the shape of the old fluorescent lamp, but in a modern and urban shape. That is the Pondero; a pendant luminaire in a body of untreated steel with aluminium gables. Already a contemporary classic from Fagerhult. The...

More about the family Pondero

Document

Instruction for use

Manual Organic Response

Material data declaration

DWG

FBX

3Ds

Max

Revit

Specification

Panel 1

Filter

Showing 8 of 8 articles

Art.no.	System Wattage	Lumen output	CCT, K	Colour	Module	Length, mm	Width, mm	Height, mm	Light distribution	Light control	CLO function active
Art.no.	System Wattage	Lumen output	CCT, K	Colour	Module	Length, mm	Width, mm	Height, mm	Light distribution	Light control	CLO function active
16980-402	33	4223	3000	Aluminium	1500	1678	80	105	Direct	DALI/Phase-pulse	Yes	IES Eulumdat Dialux
16980-533	35	4223	3000	Aluminium	1500	1678	80	105	Direct	Organic Response	Yes	IES Eulumdat Dialux
16981-402	33	4345	4000	Aluminium	1500	1678	80	105	Direct	DALI/Phase-pulse	Yes	IES Eulumdat Dialux
16981-533	35	4345	4000	Aluminium	1500	1678	80	105	Direct	Organic Response	Yes	IES Eulumdat Dialux
16982-402	23	2906	3000	Aluminium	1200	1283	80	105	Direct	DALI/Phase-pulse	Yes	IES Eulumdat Dialux
16982-533	24	2906	3000	Aluminium	1200	1283	80	105	Direct	Organic Response	Yes	IES Eulumdat Dialux
16983-402	23	2990	4000	Aluminium	1200	1283	80	105	Direct	DALI/Phase-pulse	Yes	IES Eulumdat Dialux
16983-533	24	2990	4000	Aluminium	1200	1283	80	105	Direct	Organic Response	Yes	IES Eulumdat Dialux

Accessories Notor G2 Ripustettava suora/epäsuora Lamell

Filter

Name	Description	Art.no.
Name	Description	Art.no.
Organic Response EnOcean Wireless Push button panel	EnOcean 2 function push button panel, labeled, white	86436
Organic Response EnOcean Wireless Push button panel	EnOcean 2 function push button panel, white	86416
Organic Response EnOcean Wireless Push button panel	EnOcean 4 function push button panel, labeled, white	86437
Organic Response EnOcean Wireless Push button panel	EnOcean 4 function push button panel, white	86417
Organic Response IoT Gateway	Gateway for connection to Organic Response Portal. Incl. power adapter and wall bracket. Controls a maximum of 150 sensors.	86296
Organic Response I/O box	I/O box with potential-free 16A relay for controlling external units.	86413
Organic Response I/O box	I/O box with potential-free 8A relay for controlling external units.	86433
IR dongle for Organic Response	IR dongle for Organic Response equipped luminaire.	86279
Ceiling cup	Large round ceiling cup without wire and mains cable for T-bars 25 mm/each	96395
Ceiling cup	Large round ceiling cup without wire and mains cable/each	96394
Ceiling cup	Large square ceiling cup without wire and mains cable for T-bars 25 mm/each	96399
Ceiling cup	Large square ceiling cup without wire and mains cable/each	96398
Ceiling cup	Small round ceiling cup for T-bars 25 mm/each without wire.	96397
Ceiling cup	Small round ceiling cup/each without wire.	96396
Ceiling cup	Small square ceiling cup for T-bars 25 mm/each without wire.	96401
Ceiling cup	Small square ceiling cup/each without wire.	96400
Wire suspension for support rails L: 1,5m	Wire suspension for support rails 90015, 90016, 90017, 94052, 94067, 94068	91426
Ceiling bracket in chrome with wire	Wire suspension with ceiling bracket in chrome, L=1.5 m/pair	91696
Wire	Wire with ball, 1.5 m/pair	91425
