16086-20575 Notor 36 ceiling Opal

Light distribution

Direct

Louvre

Opal

Colour

White

Lumen output

5249

CLO function active

Yes

CLO time, h

50000

lm/W

123

CCT, K

4000

CRI

80

SDCM

3

Melanopic DER

0.600

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L86

Lumen maintenance 100 000 h

L82

Lumen maintenance L100 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Driver brand

Osram

DALI generation/adress type

Dali-2/1xDT6

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

20

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

Start W

43

End W

48

Average W

45.5

Stand by W

0.25

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

12

MCB B16A

20

MCB C10A

21

MCB C16A

33

THD, %

10

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.95

Length, mm

1125

Width, mm

1125

Height, mm

36

Weight, kg

2.2
