16086-20477 Notor 36 ceiling Opal

Light distribution

Direct

Louvre

Opal

Colour

White

Lumen output

2566

CLO function active

Yes

CLO time, h

50000

lm/W

116

CCT, K

4000

CRI

80

SDCM

3

Melanopic DER

0.600

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L86

Lumen maintenance 100 000 h

L82

Lumen maintenance L100 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Driver brand

Osram

DALI generation/adress type

Dali-2/1xDT6

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

20

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

Start W

22

End W

24

Average W

23

Stand by W

0.25

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

18

MCB B16A

30

MCB C10A

31

MCB C16A

50

THD, %

12

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.85

Length, mm

563

Width, mm

36

Height, mm

563

Weight, kg

1.4
