302270-20003 Rondo G3 post top

Light distribution

Symmetrical

Colour

Grey

Lumen output

8004

CLO function active

Yes

CLO time, h

100000

lm/W

112

Light source colour

830

CCT, K

3000

CRI

80

SDCM

3

Melanopic DER

0.460

Lumen maintenance 100 000 h

L100

Lumen maintenance L100 B50, h

100000

LED driver, h/max failure %

100000/10

Energy class, LED module

E

Light control

DALI

Driver brand

Tridonic

DALI generation/adress type

Dali-2/2xDT6

Switch control, max no.

12

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

65

IK rating

10

Start W

72

End W

80

Average W

76

Stand by W

0.2

Min. ambient temperature, °C

-40

Max. ambient temperature, °C

25

MCB B10A, pcs

6

MCB B16A

10

MCB C10A

10

MCB C16A

16

Surge protection CM, kV/kA

8

Surge protection DM, kV/kA

6

Power factor, 100 %

0.97

Power factor, 20 %

0.79

Projected wind area, m2

0.150

NTC function

Yes

Length, mm

714

Width, mm

184

Height, mm

291

Weight, kg

11.8
