Multilume Dropped

A recessed luminaire for most types of suspended ceilings. The opal louvre lowers the suspended ceiling's surface and creates ambient light on the ceiling.

Installation

Recessed mounting in ventilated or unventilated suspended ceilings. Two optional designs.

VTB – for suspended ceilings with visible T-bars 15 or 24 mm.

HB – for suspended ceiling with concealed T-bars, symmetrical attachment of ceiling boards (20–22 mm thick). Supplement with fixing brackets for fixed suspended ceiling, see Accessories.

Connection

Connection in separate ballast box. Snap-in terminal block 3x1,5 mm² (x2), through-wiring possible. 5x1,5 mm² (x2) when dimming. Can also be supplied with mains cable and earthed plug or chassis mounted snap-in connector. The luminaire housing and driver are connected via a Quick Connection System.

Design

Luminaire body in white enamelled sheet steel (RAL 9016).

Louvre

Opal – opal plate in frosted acrylic (PMMA).

Miscellaneous

Enclosure class IP 44 under suspended ceilings and IP 20 above suspended ceilings.
Class III applies to the luminaire body only. The supplied driver should be connected to protective earth.

Multilume

Multilume is Fagerhult’s extensive family of LED luminaires for recessed mounting. Multilume’s balanced work and general lighting delivers excellent light ergonomics, constantly updated with the latest in LED technology....

More about the family Multilume

Document

Specification

Filter

Showing 108 of 108 articles

Art.no.System WattageLumen outputCCT, KCRIModuleInstallationLight controlConnectionCLO function active
Art.no.System WattageLumen outputCCT, KCRIModuleInstallationLight controlConnectionCLO function active
23840 20 3080 3000 80 600x600 VTB
23840-111 20 3080 3000 80 600x600 VTB Wieland GST18i3 3-way male
23840-3 20 3080 3000 80 600x600 VTB Connection cable with plug, L=2.5 m
23840-340 20 3080 3000 80 600x600 VTB Wago Winsta 3-way male
23840-402 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Yes
23840-519 20 3080 3000 80 600x600 VTB Ensto 3-way male
23840-520 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23840-528 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23840-529 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23841 20 3080 3000 80 600x600 HB
23841-111 20 3080 3000 80 600x600 VTB Wieland GST18i3 3-way male
23841-3 20 3080 3000 80 600x600 HB Connection cable with plug, L=2.5 m
23841-340 20 3080 3000 80 600x600 VTB Wago Winsta 3-way male
23841-402 18 2772 3000 80 600x600 HB DALI/Phase-pulse Yes
23841-519 20 3080 3000 80 600x600 VTB Ensto 3-way male
23841-520 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23841-528 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23841-529 18 2772 3000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23842 20 3169 4000 80 600x600 VTB
23842-111 20 3169 4000 80 600x600 VTB Wieland GST18i3 3-way male
23842-3 20 3169 4000 80 600x600 VTB Connection cable with plug, L=2.5 m
23842-340 20 3169 4000 80 600x600 VTB Wago Winsta 3-way male
23842-402 18 2852 4000 80 600x600 VTB DALI/Phase-pulse Yes
23842-519 20 3169 4000 80 600x600 VTB Ensto 3-way male
23842-520 18 2852 4000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23842-528 18 2852 4000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23842-529 18 2852 4000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23843 20 3169 4000 80 600x600 HB
23843-111 20 3169 4000 80 600x600 HB Wieland GST18i3 3-way male
23843-3 20 3169 4000 80 600x600 HB Connection cable with plug, L=2.5 m
23843-340 20 3169 4000 80 600x600 HB Wago Winsta 3-way male
23843-402 18 2852 4000 80 600x600 HB DALI/Phase-pulse Yes
23843-519 20 3169 4000 80 600x600 HB Ensto 3-way male
23843-520 18 2852 4000 80 600x600 HB DALI/Phase-pulse Ensto 5-way male Yes
23843-528 18 2852 4000 80 600x600 HB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23843-529 18 2852 4000 80 600x600 HB DALI/Phase-pulse Wago Winsta 5-way male Yes
23844 32 4951 3000 80 600x600 VTB
23844-111 32 4951 3000 80 600x600 VTB Wieland GST18i3 3-way male
23844-3 32 4951 3000 80 600x600 VTB Connection cable with plug, L=2.5 m
23844-340 32 4951 3000 80 600x600 VTB Wago Winsta 3-way male
23844-402 29 4463 3000 80 600x600 VTB DALI/Phase-pulse Yes
23844-519 32 4951 3000 80 600x600 VTB Ensto 3-way male
23844-520 29 4463 3000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23844-528 29 4463 3000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23844-529 29 4463 3000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23845 32 4951 3000 80 600x600 HB
23845-111 32 4951 3000 80 600x600 HB Wieland GST18i3 3-way male
23845-3 32 4951 3000 80 600x600 HB Connection cable with plug, L=2.5 m
23845-340 32 4951 3000 80 600x600 HB Wago Winsta 3-way male
23845-402 29 4463 3000 80 600x600 HB DALI/Phase-pulse Yes
23845-519 32 4951 3000 80 600x600 HB Ensto 3-way male
23845-520 29 4463 3000 80 600x600 HB DALI/Phase-pulse Ensto 5-way male Yes
23845-528 29 4463 3000 80 600x600 HB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23845-529 29 4463 3000 80 600x600 HB DALI/Phase-pulse Wago Winsta 5-way male Yes
23846 32 5094 4000 80 600x600 VTB
23846-111 32 5094 4000 80 600x600 VTB Wieland GST18i3 3-way male
23846-3 32 5094 4000 80 600x600 VTB Connection cable with plug, L=2.5 m
23846-340 32 5094 4000 80 600x600 VTB Wago Winsta 3-way male
23846-402 29 4592 4000 80 600x600 VTB DALI/Phase-pulse Yes
23846-519 32 5094 4000 80 600x600 VTB Ensto 3-way male
23846-520 29 4592 4000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23846-528 29 4592 4000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23846-529 29 4592 4000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23847 32 5094 4000 80 600x600 HB
23847-111 32 5094 4000 80 600x600 HB Wieland GST18i3 3-way male
23847-3 32 5094 4000 80 600x600 HB Connection cable with plug, L=2.5 m
23847-340 32 5094 4000 80 600x600 HB Wago Winsta 3-way male
23847-402 29 4592 4000 80 600x600 HB DALI/Phase-pulse Yes
23847-519 32 5094 4000 80 600x600 HB Ensto 3-way male
23847-520 29 4592 4000 80 600x600 HB DALI/Phase-pulse Ensto 5-way male Yes
23847-528 29 4592 4000 80 600x600 HB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23847-529 29 4592 4000 80 600x600 HB DALI/Phase-pulse Wago Winsta 5-way male Yes
23884 28 4253 3000 80 600x600 VTB
23884-111 28 4253 3000 80 600x600 VTB Wieland GST18i3 3-way male
23884-3 28 4253 3000 80 600x600 VTB Connection cable with plug, L=2.5 m
23884-340 28 4253 3000 80 600x600 VTB Wago Winsta 3-way male
23884-402 25 3832 3000 80 600x600 VTB DALI/Phase-pulse Yes
23884-519 28 4253 3000 80 600x600 VTB Ensto 3-way male
23884-520 25 3832 3000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23884-528 25 3832 3000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23884-529 25 3832 3000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23885 28 4253 3000 80 600x600 HB
23885-111 28 4253 3000 80 600x600 HB Wieland GST18i3 3-way male
23885-3 28 4253 3000 80 600x600 HB Connection cable with plug, L=2.5 m
23885-340 28 4253 3000 80 600x600 HB Wago Winsta 3-way male
23885-402 25 3832 3000 80 600x600 HB DALI/Phase-pulse Yes
23885-519 28 4253 3000 80 600x600 HB Ensto 3-way male
23885-520 25 3832 3000 80 600x600 HB DALI/Phase-pulse Ensto 5-way male Yes
23885-528 25 3832 3000 80 600x600 HB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23885-529 25 3832 3000 80 600x600 HB DALI/Phase-pulse Wago Winsta 5-way male Yes
23886 28 4375 4000 80 600x600 VTB
23886-111 28 4375 4000 80 600x600 VTB Wieland GST18i3 3-way male
23886-3 28 4375 4000 80 600x600 VTB Connection cable with plug, L=2.5 m
23886-340 28 4375 4000 80 600x600 VTB Wago Winsta 3-way male
23886-402 25 3943 4000 80 600x600 VTB DALI/Phase-pulse Yes
23886-519 28 4375 4000 80 600x600 VTB Ensto 3-way male
23886-520 25 3943 4000 80 600x600 VTB DALI/Phase-pulse Ensto 5-way male Yes
23886-528 25 3943 4000 80 600x600 VTB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23886-529 25 3943 4000 80 600x600 VTB DALI/Phase-pulse Wago Winsta 5-way male Yes
23887 28 4375 4000 80 600x600 HB
23887-111 28 4375 4000 80 600x600 HB Wieland GST18i3 3-way male
23887-3 28 4375 4000 80 600x600 HB Connection cable with plug, L=2.5 m
23887-340 28 4375 4000 80 600x600 HB Wago Winsta 3-way male
23887-402 25 3943 4000 80 600x600 HB DALI/Phase-pulse Yes
23887-519 28 4375 4000 80 600x600 HB Ensto 3-way male
23887-520 25 3943 4000 80 600x600 HB DALI/Phase-pulse Ensto 5-way male Yes
23887-528 25 3943 4000 80 600x600 HB DALI/Phase-pulse Wieland GST18i5 5-way male Yes
23887-529 25 3943 4000 80 600x600 HB DALI/Phase-pulse Wago Winsta 5-way male Yes

Filter

NameDescriptionArt.no.
NameDescriptionArt.no.
Ensto T-connector Ensto T-connector 3-way, white 92783
Ensto T-connector Ensto T-connector 5-way, grey 92784
Fence Fence 600x600 black. Only for T-bars T24. 41253
Fence Fence 600x600 champagne. Only for T-bars T24. 41254
Fence Fence 600x600 white. Only for T-bars T24. 41252
Fixing brackets Fixing brackets/4 pcs. For fixed ceiling. Only for concealed T-bars (HB-body). 91279
Frame for surface mounting Frame for surface mounting (600x600 VTB). Fits Multilume Flat (only standard and DALI), Dwide as well as Multilume Slim, Multilume Slim Hygiene & Multilume Re:Think with Organic Response. 41026
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 3x1,5 mm². Halogen free. 92787
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 5x1,5 mm². Halogen free. 92788
WAGO connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 91244
Wieland connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92793
no-image placeholder Ensto connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92785
WAGO connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 91243
Wieland connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92799
no-image placeholder Ensto connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92786
Recessed frame solid ceiling Recessed frame for VTB frame 600x600 in solid ceiling (ceiling thickness 5 – 50 mm) Max. weight 4,5kg 41051
no-image placeholder Recessed frame Recessed frame to Multilume Flat 600x600 VTB body for installation in suspended ceilings with concealed T-bars and symmetrical ceiling tiles (thickness 20-22 mm). 41038
Sky frame Sky frame for ceiling window effect 600x600, white. Only for T-bars T24. 41245
WAGO T-connector WAGO T-Connector, 3-way, white 91067
WAGO T-connector WAGO T-connector, 5-way, 2 locking levers, blue 88228
Wieland T-connector Wieland 3-way T-connector 91025
Wieland T-connector Wieland 5-way T-connector 91026
