23858-529 Multilume Edge

Installation

VTB

Module

600x600

Light distribution

Direct

Louvre

Opal

Colour

White

RAL

9016

Lumen output

2803

CLO function active

Yes

CLO time, h

50000

lm/W

157

CCT, K

3000

CRI

80

SDCM

3

Melanopic DER

0.450

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L86

Lumen maintenance 100 000 h

L82

Lumen maintenance L100 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Light control

DALI/Phase-pulse

Driver brand

Tridonic

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

25

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Connection

Wago Winsta 5-way male

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

44

IP rating (above suspended ceilings)

20

Start W

18

End W

20

Average W

19

Stand by W

0.15

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

19

MCB B16A

31

MCB C10A

31

MCB C16A

51

THD, %

10

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.93

Length, mm

596

Width, mm

596

Height, mm

72

Weight, kg

5
