39348-35 Kaptur

Light distribution

Direct

Louvre

Opal

Diffuser

PC

Colour

Grey

Lumen output

8577

lm/W

138

CCT, K

3000

CRI

80

SDCM

3

Melanopic DER

0.480

Lumen maintenance 50 000 h

L89

Lumen maintenance 75 000 h

L85

Lumen maintenance 100 000 h

L80

Lumen maintenance L80 B50, h

100000

Lumen maintenance L90 B50, h

45000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

PstLm

0.800

SVM

0.300

Driver brand

Philips

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

67

IK rating

08

System Wattage

62

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

12

MCB B16A

18

MCB C10A

18

MCB C16A

30

THD, %

3

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Leakage current PE

0.400

Power factor, 100 %

0.97

Length, mm

1500

Width, mm

123

Height, mm

100

Weight, kg

4.000
