87226-20009 Fjord

Module

900

Light distribution

Asymmetrical

Colour

Grey

Lumen output

342

CLO function active

Yes

CLO time, h

100000

lm/W

67

CCT, K

3000

CRI

80

SDCM

3

Lumen maintenance 100 000 h

L100

LED driver, h/max failure %

100000/10

Energy class, LED module

E

Light control

Night dimming 1

Driver brand

Philips

Power on last level

Yes

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

65

IP rating (above suspended ceilings)

44

IK rating

10

Start W

5.1

End W

5.5

Average W

5.5

Stand by W

0.5

Min. ambient temperature, °C

40

Max. ambient temperature, °C

25

MCB B10A, pcs

30

MCB B16A

48

MCB C10A

49

MCB C16A

81

THD, %

12

Surge protection CM, kV/kA

10

Surge protection DM, kV/kA

6

Power factor, 100 %

0.96

Projected wind area, m2

0.156

Height, mm

980

Diamater, mm

233

Weight, kg

7.500
