22352-535 Dwide Pendant

Module

180x1500

Light distribution

60/40

Louvre

Delta

Colour

White

Lumen output

4898

CLO function active

Yes

CLO time, h

50000

lm/W

133

CCT, K

3000

CRI

80

SDCM

3

Melanopic DER

0.450

Lumen maintenance 50 000 h

L100

Lumen maintenance 75 000 h

L86

Lumen maintenance 100 000 h

L82

Lumen maintenance L100 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Light control

e-Sense BrightSwitch on/off

Driver brand

Osram

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

20

AM

Yes

ZD4i Certified

False

Detection technology

IR

Detection type

Presence

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

Start W

37

End W

41

Average W

39

Stand by W

0.15

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

12

MCB B16A

20

MCB C10A

20

MCB C16A

34

THD, %

18

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.99

Length, mm

1720

Width, mm

177

Height, mm

50

Weight, kg

4.8
