22201-519 Dwide recessed

Installation

VTB

Module

600x600

Light distribution

Direct

Louvre

Delta

Colour

White

Lumen output

4390

lm/W

137

CCT, K

4000

CRI

80

SDCM

3

Melanopic DER

0.650

Lumen maintenance 50 000 h

L90

Lumen maintenance 75 000 h

L85

Lumen maintenance 100 000 h

L80

Lumen maintenance L80 B50, h

100000

Lumen maintenance L90 B50, h

50000

LED driver, h/max failure %

100000/10

Energy class, LED module

C

Driver brand

Tridonic

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

System Wattage

32

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

11

MCB B16A

17

MCB C10A

18

MCB C16A

28

THD, %

12

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Power factor, 100 %

0.95

Length, mm

595

Width, mm

595

Height, mm

57

Weight, kg

3.600
