Notor 65 Delta

Available in April 2017.

Installation
Single or continuous installation via wire suspension or surface mounted. Installation via wire suspension requires wire brackets which provide flexible c/c, see accessories. See wire suspension. Can also be wall mounted with special brackets, see Accessories.

Connection
The luminaire is equipped with an access hole for cabling on the top. A special short end with cable entry is used for a surface mounted mains cable, see Accessories. The luminaire unit is equipped with a through-wiring cable (5x1.5 mm²) and a snap-in connection in each end-cap. In a continuous installation, the luminaire row should always begin with a start luminaire. The illuminated corners can be used as a start luminaire and are equipped with through-wiring and quick connection in one end. The corners can only be used in closed systems.

Design
Luminaire body enameled in white (RAL 9016) or natural anodised, extruded aluminium finish. The indirect light is covered by an opal film which generates a wide beam and acts as a dust cover. End caps are included in the Start/Single-luminaire.

Louvre
Delta – microprism louvre in acrylic (PMMA.

Emergency lighting
There is a unit with integrated emLED available for Notor 65, see Accessories.

Dimming
CLO (Constant Light Output) and DALI/Phase-pulse control as standard. CLO means that the luminaire provides the same amount of light throughout its service life. Suffix number -442 och -449 only refer to single luminaires.

Accessories
Assembly fittings and supplementary components, see Accessories.

LED-information
3000/4000 K: Ra (CRI) min. 80, MacAdam 3 SDCM.
Driver life-time: up to 100.000 h/10 % (max failure).
Ra (CRI) 90 on request.

Miscellaneous
The LEDs are protected against contact.
800 mm 2.0 kg
1200 mm 3.0 kg
2400 mm 6.0 kg
Illuminated corner 2.5 kg

Environment images


Marking of product sheet

Document added to your cart

Text som beskriver tabellen
W Module Colour CCT (K) Light distribution lm lm/W Useful life Art.No.
LED (system)
Continuous, High Lumen (HL)
23 800 Anodised 3000 Direct 2216 96 L100B50 50.000 h 13405-402
23 800 Anodised 4000 Direct 2333 101 L100B50 50.000 h 13407-402
23 800 White 3000 Direct 2216 96 L100B50 50.000 h 13409-402
23 800 White 4000 Direct 2333 101 L100B50 50.000 h 13411-402
36 1200 Anodised 3000 Direct 3325 92 L100B50 50.000 h 13413-402
36 1200 Anodised 4000 Direct 3500 97 L100B50 50.000 h 13415-402
36 1200 White 3000 Direct 3325 92 L100B50 50.000 h 13417-402
36 1200 White 4000 Direct 3500 97 L100B50 50.000 h 13419-402
43 1200 Anodised 3000 Direct/indirect 4750 109 L100B50 50.000 h 13421-402
43 1200 Anodised 4000 Direct/indirect 5000 115 L100B50 50.000 h 13423-402
43 1200 White 3000 Direct/indirect 4750 109 L100B50 50.000 h 13425-402
43 1200 White 4000 Direct/indirect 5000 115 L100B50 50.000 h 13427-402
70 2400 Anodised 3000 Direct 6650 95 L100B50 50.000 h 13429-402
70 2400 Anodised 4000 Direct 7000 100 L100B50 50.000 h 13431-402
70 2400 White 3000 Direct 6650 95 L100B50 50.000 h 13433-402
70 2400 White 4000 Direct 7000 100 L100B50 50.000 h 13435-402
87 2400 Anodised 3000 Direct/indirect 9500 109 L100B50 50.000 h 13437-402
87 2400 Anodised 4000 Direct/indirect 10000 115 L100B50 50.000 h 13439-402
87 2400 White 3000 Direct/indirect 9500 109 L100B50 50.000 h 13441-402
87 2400 White 4000 Direct/indirect 10000 115 L100B50 50.000 h 13443-402
Continuous, Low Lumen (LL)
12 800 Anodised 3000 Direct 983 82 L100B50 50.000 h 13404-402
12 800 Anodised 4000 Direct 1033 86 L100B50 50.000 h 13406-402
12 800 White 3000 Direct 983 82 L100B50 50.000 h 13408-402
12 800 White 4000 Direct 1033 86 L100B50 50.000 h 13410-402
19 1200 Anodised 3000 Direct 1473 79 L100B50 50.000 h 13412-402
19 1200 Anodised 4000 Direct 1550 83 L100B50 50.000 h 13414-402
19 1200 White 3000 Direct 1473 79 L100B50 50.000 h 13416-402
19 1200 White 4000 Direct 1550 83 L100B50 50.000 h 13418-402
32 1200 Anodised 3000 Direct/indirect 3325 104 L100B50 50.000 h 13420-402
32 1200 Anodised 4000 Direct/indirect 3500 109 L100B50 50.000 h 13422-402
32 1200 White 3000 Direct/indirect 3325 104 L100B50 50.000 h 13424-402
32 1200 White 4000 Direct/indirect 3500 109 L100B50 50.000 h 13426-402
32 2400 Anodised 3000 Direct 2945 91 L100B50 50.000 h 13428-402
32 2400 Anodised 4000 Direct 3100 96 L100B50 50.000 h 13430-402
32 2400 White 3000 Direct 2945 91 L100B50 50.000 h 13432-402
32 2400 White 4000 Direct 3100 96 L100B50 50.000 h 13434-402
64 2400 Anodised 3000 Direct/indirect 6650 109 L100B50 50.000 h 13436-402
64 2400 Anodised 4000 Direct/indirect 7000 104 L100B50 50.000 h 13438-402
64 2400 White 3000 Direct/indirect 6650 109 L100B50 50.000 h 13440-402
64 2400 White 4000 Direct/indirect 7000 104 L100B50 50.000 h 13442-402
Illuminated corner, continuous, left, Low Lumen (LL)
12 400x400 Anodised 3000 Direct 983 82 L100B50 50.000 h 13548-402
12 400x400 Anodised 4000 Direct 1033 86 L100B50 50.000 h 13550-402
12 400x400 White 3000 Direct 983 82 L100B50 50.000 h 13552-402
12 400x400 White 4000 Direct 1033 86 L100B50 50.000 h 13554-402
Illuminated corner, continuous, right, Low Lumen (LL)
12 400x400 Anodised 3000 Direct 983 82 L100B50 50.000 h 13549-402
12 400x400 Anodised 4000 Direct 1033 86 L100B50 50.000 h 13551-402
12 400x400 White 3000 Direct 983 82 L100B50 50.000 h 13553-402
12 400x400 White 4000 Direct 1033 86 L100B50 50.000 h 13555-402
Illuminated corner, start/single, right, Low Lumen (LL)
12 400x400 Anodised 3000 Direct 983 82 L100B50 50.000 h 13557-402
12 400x400 Anodised 4000 Direct 1033 86 L100B50 50.000 h 13559-402
12 400x400 White 3000 Direct 983 82 L100B50 50.000 h 13561-402
12 400x400 White 4000 Direct 1033 86 L100B50 50.000 h 13563-402
Start/Single, High Lumen (HL)
23 800 Anodised 3000 Direct 2216 96 L100B50 50.000 h 13365-402
23 800 Anodised 4000 Direct 2333 101 L100B50 50.000 h 13367-402
23 800 White 3000 Direct 2216 96 L100B50 50.000 h 13369-402
23 800 White 4000 Direct 2333 101 L100B50 50.000 h 13371-402
36 1200 Anodised 3000 Direct 3325 92 L100B50 50.000 h 13373-402
36 1200 Anodised 4000 Direct 3500 97 L100B50 50.000 h 13375-402
36 1200 White 3000 Direct 3325 92 L100B50 50.000 h 13377-402
36 1200 White 4000 Direct 3500 97 L100B50 50.000 h 13379-402
43 1200 Anodised 3000 Direct/indirect 4750 109 L100B50 50.000 h 13381-402
43 1200 Anodised 4000 Direct/indirect 5000 115 L100B50 50.000 h 13383-402
43 1200 White 3000 Direct/indirect 4750 109 L100B50 50.000 h 13385-402
43 1200 White 4000 Direct/indirect 5000 115 L100B50 50.000 h 13387-402
70 2400 Anodised 3000 Direct 6650 95 L100B50 50.000 h 13389-402
70 2400 Anodised 4000 Direct 7000 100 L100B50 50.000 h 13391-402
70 2400 White 3000 Direct 6650 95 L100B50 50.000 h 13393-402
70 2400 White 4000 Direct 7000 100 L100B50 50.000 h 13395-402
87 2400 Anodised 3000 Direct/indirect 9500 109 L100B50 50.000 h 13397-402
87 2400 Anodised 4000 Direct/indirect 10000 115 L100B50 50.000 h 13399-402
87 2400 White 3000 Direct/indirect 9500 109 L100B50 50.000 h 13401-402
87 2400 White 4000 Direct/indirect 10000 115 L100B50 50.000 h 13403-402
Start/Single, Low Lumen (LL)
12 800 Anodised 3000 Direct 983 82 L100B50 50.000 h 13364-402
12 800 Anodised 4000 Direct 1033 86 L100B50 50.000 h 13366-402
12 800 White 3000 Direct 983 82 L100B50 50.000 h 13368-402
12 800 White 4000 Direct 1033 86 L100B50 50.000 h 13370-402
19 1200 Anodised 3000 Direct 1473 79 L100B50 50.000 h 13372-402
19 1200 Anodised 4000 Direct 1550 83 L100B50 50.000 h 13374-402
19 1200 White 3000 Direct 1473 79 L100B50 50.000 h 13376-402
19 1200 White 4000 Direct 1550 83 L100B50 50.000 h 13378-402
32 1200 Anodised 3000 Direct/indirect 3325 104 L100B50 50.000 h 13380-402
32 1200 Anodised 4000 Direct/indirect 3500 109 L100B50 50.000 h 13382-402
32 1200 White 3000 Direct/indirect 3325 104 L100B50 50.000 h 13384-402
32 1200 White 4000 Direct/indirect 3500 109 L100B50 50.000 h 13386-402
32 2400 Anodised 3000 Direct 2945 91 L100B50 50.000 h 13388-402
32 2400 Anodised 4000 Direct 3100 96 L100B50 50.000 h 13390-402
32 2400 White 3000 Direct 2945 91 L100B50 50.000 h 13392-402
32 2400 White 4000 Direct 3100 96 L100B50 50.000 h 13394-402
64 2400 Anodised 3000 Direct/indirect 6650 109 L100B50 50.000 h 13396-402
64 2400 Anodised 4000 Direct/indirect 7000 104 L100B50 50.000 h 13398-402
64 2400 White 3000 Direct/indirect 6650 109 L100B50 50.000 h 13400-402
64 2400 White 4000 Direct/indirect 7000 104 L100B50 50.000 h 13402-402
Text som beskriver tabellen
W Module Colour CCT (K) Light distribution lm lm/W Useful life Art.No.
LED (system)
Start/Single, High Lumen (HL)
36 1200 Anodised 3000 Direct 3325 92 L100B50 50.000 h 13373-449
36 1200 Anodised 4000 Direct 3500 97 L100B50 50.000 h 13375-449
36 1200 White 3000 Direct 3325 92 L100B50 50.000 h 13377-449
36 1200 White 4000 Direct 3500 97 L100B50 50.000 h 13379-449
43 1200 Anodised 3000 Direct/indirect 4750 109 L100B50 50.000 h 13381-449
43 1200 Anodised 4000 Direct/indirect 5000 115 L100B50 50.000 h 13383-449
43 1200 White 3000 Direct/indirect 4750 109 L100B50 50.000 h 13385-449
43 1200 White 4000 Direct/indirect 5000 115 L100B50 50.000 h 13387-449
Start/Single, Low Lumen (LL)
19 1200 Anodised 3000 Direct 1473 79 L100B50 50.000 h 13372-449
19 1200 Anodised 4000 Direct 1550 83 L100B50 50.000 h 13374-449
19 1200 White 3000 Direct 1473 79 L100B50 50.000 h 13376-449
19 1200 White 4000 Direct 1550 83 L100B50 50.000 h 13378-449
32 1200 Anodised 3000 Direct/indirect 3325 104 L100B50 50.000 h 13380-449
32 1200 Anodised 4000 Direct/indirect 3500 109 L100B50 50.000 h 13382-449
32 1200 White 3000 Direct/indirect 3325 104 L100B50 50.000 h 13384-449
32 1200 White 4000 Direct/indirect 3500 109 L100B50 50.000 h 13386-449
Text som beskriver tabellen
W Module Colour CCT (K) Light distribution lm lm/W Useful life Art.No.
LED (system)
Start/Single, High Lumen (HL)
36 1200 Anodised 3000 Direct 3325 92 L100B50 50.000 h 13373-442
36 1200 Anodised 4000 Direct 3500 97 L100B50 50.000 h 13375-442
36 1200 White 3000 Direct 3325 92 L100B50 50.000 h 13377-442
36 1200 White 4000 Direct 3500 97 L100B50 50.000 h 13379-442
43 1200 Anodised 3000 Direct/indirect 4750 109 L100B50 50.000 h 13381-442
43 1200 Anodised 4000 Direct/indirect 5000 115 L100B50 50.000 h 13383-442
43 1200 White 3000 Direct/indirect 4750 109 L100B50 50.000 h 13385-442
43 1200 White 4000 Direct/indirect 5000 115 L100B50 50.000 h 13387-442
Start/Single, Low Lumen (LL)
19 1200 Anodised 3000 Direct 1473 79 L100B50 50.000 h 13372-442
19 1200 Anodised 4000 Direct 1550 83 L100B50 50.000 h 13374-442
19 1200 White 3000 Direct 1473 79 L100B50 50.000 h 13376-442
19 1200 White 4000 Direct 1550 83 L100B50 50.000 h 13378-442
32 1200 Anodised 3000 Direct/indirect 3325 104 L100B50 50.000 h 13380-442
32 1200 Anodised 4000 Direct/indirect 3500 109 L100B50 50.000 h 13382-442
32 1200 White 3000 Direct/indirect 3325 104 L100B50 50.000 h 13384-442
32 1200 White 4000 Direct/indirect 3500 109 L100B50 50.000 h 13386-442

emLED-unit

Battery, 3 hours, selftest DALI, luminaire must be connected as DALI.

Art.No.
Anodised, Continuous luminaire emLED-unit, 270 mm 92678
White, Continuous luminaire emLED-unit, 270 mm 92679

End-cap

End-cap with hole for surface mounted cable.

Art.No.
Anodised, End-cap/each 92676
White, End-cap/each 92677

External sensor for e-Sense Actilume

When presence detecting in larger area is required, one or several sensors type LRM 8118 can be connected to any of the DALI-terminal block in the luminaire. No programming or commissioning needed. LRM 8118 should be placed in the ceiling, and have a detecting area of 7×7 m. LRM 8118 is only presence detection.

Art.No.
External sensor LRM8118 86152

Remote control for e-Sense ActiLume

If changed function is required, a number of modes can be programmed by the remote control. The system is programmed with nine preset modes for e.g. school, corridor, etc.

Art.No.
Remote control 86155

Spacers

Spacers as continuous luminaire incl. through-wiring.

Art.No.
Anodised, Spacers 200 mm 92660
White, Spacers 200 mm 92661
Anodised, Spacers 400 mm 92662
White, Spacers 400 mm 92663
Anodised, Spacers 600 mm 92664
White, Spacers 600 mm 92665
Anodised, Spacers 800 mm 92666
White, Spacers 800 mm 92667
Anodised, Spacers 1000 mm 92668
White, Spacers 1000 mm 92669
Anodised, Spacers 1200 mm 92670
White, Spacers 1200 mm 92671

Surface mounted box for e-Sense ActiLume

Art.No.
Surface mounted box LRM8118 86164

Wall bracket

Art.No.
Anodised, Wall bracket 92674
White, Wall bracket 92675

Wall bracket

Art.No.
Anodised, Wall bracket with terminal block 92685
White, Wall bracket with terminal block 92686

Wall panel for e-Sense Actilume

The unit has only two switches, one for on/increase light level, one for off/decrease the light level.

Art.No.
Wall panel IRT 8050 86151

Wall socket

Art.No.
White, Wall socket 92673

Wire bracket incl. friction locks

Art.No.
Anodised, Wire bracket/pair 92682
White, Wire bracket/pair 92683
Direct/Indirect

Direct/Indirect

Direct

Direct
